Control Type:
On/Off, PHASE-CUT, DALI , Casambi
Driver Brand:
Osram
LED Type:
COB LED
Driver Brand:
Osram
LED Brand:
Samsung
Driver Brand:
Osram
Material:
Aluminium
Body Paint:
Electrostatic powder coated, acrylic (optional)
Colour Options:
RAL9003, RAL9016, RAL9010, RAL9006, RAL7011, RAL7016,
RAL7021, RAL9004, RAL9005, other
Body Finish:
Matt, Textured
Optic:
Lens + Dark Reflector
Emergency Backup:
3-hour emergency kit available
Installation Type:
Recessed mounted
CCT:
2700/3000/4000/5000/6500K
CRI:
>80 / (optional >90)
Operating Temperature Range:
-20°C/+45°C
Working Voltage:
220-240V, 50-60Hz
Beam Angle:
50°/80°
Dimensions:
100 x 100 x 75mm
LED Lifetime (L70):
72,000 hours
Compliance:
CE
| Product Description | Power | Efficiency | UGR | Dimensions WxLxH | Cut-out Diameter | Minimum Recessed Depth |
|---|---|---|---|---|---|---|
| EA-DX-SQ4R-6 | 6W | up to 115lm/W | <19 | 100x100x75mm | 90x90mm | w/O KIT: 75mm w/EMG KIT: 210mm |
| EA-DX-SQ4R-8 | 8W | |||||
| EA-DX-SQ4R-10 | 10W | |||||
| EA-DX-SQ4R-12 | 12W | |||||
| EA-DX-SQ4R-14 | 14W | |||||
| EA-DX-SQ4R-20 | 20W | |||||
| EA-DX-SQ4R-24 | 24W | |||||
| EA-DX-SQ4R-28 | 28W |
All of our products use the finest components in the industry, to provide peace of mind and quality for our clients.
