5 bus bars cells, with efficiency up to 21%.
IP68 junction box for long term weather
endurance.
High quality aluminum frame, resisting load
up to 5400 Pa and wind pressure up to
2400 Pa.
High transmissivity, low-iron tempered
glass.
100% EL test, before and after lamination,
approved to ensure superior quality.
High performance in low-light environment
Cell type: Polycrystalline (156.75×156.75mm)
Operating temp. range: -45 °C ~+85 °C
Max. system voltage: 1500V
Glass: 3.2 mm tempered glass
Frame: Anodized aluminum alloy
Junction box: IP68
| Product Description | Power output Pmax | Max. power voltage (Vmp) | Max. power current (Imp) | Open circuit voltage (Voc) | Short circuit voltage (Isc) |
|---|---|---|---|---|---|
| EA-SPM010WPM203 | 10W | 18.22 V | 0.55 A | 21.92 V | 0.62 A |
| EA-SPM030WPM203 | 30W | 19.01 V | 1.58 A | 23.08 V | 1.73 A |
| EA-SPM070WPM203 | 70W | 18.55 V | 3.77 A | 22.89 V | 3.96 A |
| EA-SPM135WPM203 | 135W | 18.34 V | 7.36 A | 22.25 V | 7.76 A |
| EA-SPM350WPM203 | 350W | 38.93 V | 8.99 A | 47.12 V | 9.38 A |
All of our products use the finest components in the industry, to provide peace of mind and quality for our clients.
