Remote monitoring:
Real-time system data via GSM / 4G
Web & App)
Motion Sensor:
Automatically increases brightness when
needed
4-step Dimming:
Intelligent energy saving control
LiFePO4 Battery:
Safe, long life, high efficiency with Smart BMS
MPPT Charging:
Maximum power point tracking
System Protection:
Overcharge, overload, short circuit protection
All Weather Design:
IP65 rated system for harsh outdoor environments
Customised options:
Available upon request
System Overview & Power:
Powered by a 2.4 kWp solar array with smart MPPT charging and a 4 kW pure sine waveinverter running on a 48 V LiFePO4 battery system with smart BMS protection.
Lighting & Mast Capabilities:
• Features a telescopic mast extending up to 9 meters with 360° rotation.
• Equipped with a 300W total LED lighting setup, 4-step intelligent dimming, and optional/standard PIR and radar motion sensors.
Physical Build & Deployment:
• Built on a single-axle, road-towable trailer designed to withstand winds up to 80 km/h and operate in temperatures from -20°C to +50°C.
• Includes remote management via GSM/4G (Web & Mobile App).
• Ideal for construction, events, emergency response, military, mining, and road works.
Compliance:
CE
| ELECTRICAL / POWER | |
|---|---|
| Solar Power | 2.4 kWp (4x600W panels) |
| Charging Controller | MPPT Solar Charge Controller |
| Inventer Power | 4kW Pure Sine Wave |
| Operating Voltage | 48V DC System |
| Battery Type | LiFePO4 with Smart BMS |
| LIGHTING AND MAST | |
| LED Lighting Power | 6 x 50W (total 300W) |
| Mast Height and Rotation | Up to 9m (telescopic), 360 degrees rotable | ENVIRONMENT |
| Operating Temperature | -20°C to +50°C |
All of our products use the finest components in the industry, to provide peace of mind and quality for our clients.
